Using the on-site extrusion machinery, SKE Industries ensures the non-toxic and recycled HDPE pipes of superior quality, which have higher tensile strength and impact resistance properties.
HDPE conveyor rollers are generally used in the dusty and corrosive environment such as mining industry, iron and steel, cement, smelting, power, chemistry, construction material, coal washing, foodstuff processing, port activities etc.
1. Non-corrosive excellent abrasion resistance.
2. 50% Lighter than steel roller, long lifespan.
3. Lower start-up costs on conveyer drives.
4. Recyclable, energy efficient, decreases vibration.
5. Lowers maintenance costs, minimizes damage to conveyer belts.
6. Non-toxic HDPE pipe.
7. Water-tight sealing arrangement.
8. Performs well in harsh weather and extreme applications.
| HDPE Roller Spec. | |
| Roller Dia. (mm) | 89, 108, 133, 102, 127 |
| HDPE Tube Thickness (mm) | 9.0, 9.5, 10.5, 11.0 |
| Inner Steel Tube Dia. (mm) | 65, 80, 108, 102 |
| Inner Steel Tube Thickness. (mm) | 1.5, 2.0 |
| Roller Shaft Dia. (mm) | 20, 25 |
| Roller Length (mm) | 186 - 1632 * |
| Belt Width (mm) | 300 - 1400 |
| Bearings No. | 6204, 6205 |
| Standard | DIN, CEMA, JIS, AS,etc. |
