Barge / Ship Loading Direct From Trucks

This is a types of bulk reception feeders and it can be used as shiploader for loading barges and coaster vessels directly from dumper trucks in port and in-land terminal. The ship loading capacity can reach 1500t/h according to the truck unloading cycle time.

Send Email Send Message

KTU Truck Unloader (500PTH) Catalog

EAC Certification, CE Certificate, ISO 9001, ISO 14001, ISO 45001,

Application
Features
Gallery
Datasheet

APPLICATION

The KTU Truck Unloader allows the operator to load a barge or vessel directly from a dump truck, to avoid the double handling of material on the quayside. The materials can be aggregate, sand, coal, fertilizer, mineral ores, clinker, etc.

Ship Loading: Loading a barge direct from a Wheel Loader and Trucks or Feeding a Radial Telescopic Ship Loader to load ships like Mini Bulk Carrier, Handysize, Handymax, Supramax, Panamax, Capesize.
Ship Unloading: Fed by Grab Crane in barge unloading applications.
Rail Car / Wagon Loading & Unloading: Mobile Truck Unloader Unloading Direct from Truck or Rail Car.
Stockpiling: Mobile Truck Unloader Fed by Dumper Truck Or Wheel Loader to stack bulk materials in a stockyard.
Reclaiming: Fed by Wheel Loader to Feed a belt conveyor in a belt conveyor system.

FEATURES

It suits for unloading various of trucks like ADT trucks, tipping trucks, and mine dumper truck.
It has rotation and lifting functions and can realize automatic stacking.
This ship loader can be mounted on track or wheels to provide high flexible mobility.
You don't need to build a temporary yard to pile materials and can load rail wagons direct from trucks.
You can use it to load barges direct from trucks.
With less civil work, you can save cost on your project.

GALLERY

DATASHEET

Models	KTU
Feeding	Up to 60 ~ 100 tonnes (trucks)
Capacity	0-1500t/h (Depending on Truck Cycle times)
Feeding Method	Fed By Truck like Road Dumper Truck, ADT and Rigid Dumper Truck.
	Fed By Wheel Loader from the Rear and Side.
	Mobile Truck Unloader Fed By Railcar and Wagon.
	Fed By Grab Crane from Bulk Carrier.
Options	Dust enclosures complete with rubber curtains at feed-in point
	Dust covers
	Dust extraction units mounted at transfer points
	Telescopic discharge chute Trimmer chutes available
	Rubber sock chutes
	Spray bars for dust suppression
	Sealing of all transfer points including side plates and under-trays
	Ramps at feed-in point for trucks
	Radio remote controls
	Dual Power - Diesel and Electric
	Marine specification paint finish
