Belt Conveyor Flat Idler

The Flat Idler of belt conveyor is divided into parallel upper idler and lower idler. SKE is a professional Belt Conveyor Flat Idler Manufacturer.

  • Applications
  • Advantages
  • Datasheet
  • Related
Applications

Belt conveyor flat idler are mainly divided into ordinary type, comb idler, forward inclined  idler, steel rubber idler, spiral idler, etc. The parallel idler of belt conveyor is mainly used for supporting materials and belts. Upper flat idler and lower flat idler are applicable to be fixed on conveyors used in port ,terminal, mine, cement plant, thermal power plant, grain silo/warehouse, sand plant, etc.

Advantages

1. Easy installation ,stable operation ,good flexibility and min 30,000 hours stable lift time.

2. High accurate steel pipes ensure the rollers with wearing resisting,low vibration and noise.

3. Sealing arrangement include a double seal.

4. Dustproof, waterproof and anti-alkali and acid suitabe for corrosion environment.

5. Electrostatic spraying technical makes the roller more durable and good-looking.

Tech Datasheet
Flat Idler
Material UHMWPE material Polyamide material
Working environment Dust, pollution, temperature from -50 to 60 Centigrade Corrsive, heavy,hot temperature from 50 to 110 Centigrade
Main Properties light, self-lubricated, anti-dust,low temperature working wear resistance, heat resistance, heavy loading roller
Standard Diameter Lengthscope Bearings Type Idler's shell wall thinkness
mm Inch (mm) (Min-Max)
63.5 21/2 150-3500 204 3.0mm-3.75mm
76 3 150-3500 204 205 3.0mm-4.0mm
89 31/3 150-3500 204 205 3.0mm-4.0mm
102 4 150-3500 204 205 305 3.5mm-4.0mm
108 41/4 150-3500 204 205 305 306 3.5mm-4.0mm
114 41/2 150-3500 204 205 305 306 3.5mm-4.5mm
127 5 150-3500 204 205 305 306 3.5mm-4.5mm
133 51/4 150-3500 204 206 207 305 306  3.5mm-4.5mm
152 6 150-3500 204 206 207 305 306 307 308 4.0mm-4.5mm
159 61/4 150-3500 204 206 207 305 306 307 308 4.0mm-4.5mm
165 61/2 150-3500 207 305 306 307 308 4.5mm-6.0mm
194 75/8 150-3500 207 307 308 309 310 4.5mm-6.0mm
219 85/8 150-3500 308 309 310 4.5mm-6.0mm
