Heat Resistant Conveyor Belt

Heat resistant conveyor belt is made of the multi-ply rubber polyester cotton canvas covered with the high temperature or heat resistant resistant rubbers, and it is applicable to conveying of the coke, cement, clinker and hot casting etc.

  • Applications
  • Advantages
  • Datasheet
  • Related
APPLICATIONS

These heat resistant conveyor belts are well-suited for heat resistance applications, where the temperature of conveyed materials is over 80°C. Heat resistant conveyor belt is applicable to conveying of the coke, cement, clinker and hot casting etc. These Heat Resistant Conveyor Belt are also resistant to oils and minerals. Our range of Heat Resistant Conveyor Belt is made from optimum raw materials to assure high durability.

ADVANTAGES

Tyeps of Heat resistant conveyor belt

1. Our range of HR(T1) Conveyor Belt are heat resistant suitable for continuous Temperature up to 125 degree centigrade on belt surface and 180 degree Centigrade for material handled.
2. Our range of SHR (T2) Conveyor Belt are used for handling material up to 150 degree centigrade on belt surface and 200 degree Centigrade for material handled.
3. Our range of UHR(T3) Conveyor Belt are used for controlled high temperature Applications, it is suitable for continuous service up to 180 degree centigrade on belt surface and 220 degree Centigrade for material handled.

Features of Heat resistant conveyor belt

1. High tensile strength
2. Robust construction
3. Wear & tear resistant
4. Excellent heat & abrasion resistant cover rubber compound
5. Perfect to protect conveyor belt from cracking and hardening by heat
6. Rubber cover and carcass capable to withstand high temperature
7. Anti corrosive

DATASHEET
Heat resistant conveyor belt specifications
Grade HR(T1) SHR(T2) UHR(T3)
Max. Temp. On Belt Surface (℃) 125 150 180
Max. Temp. of Material Handled(℃) 180 200 220
Application Areas Mainly used in Paper, Foundries, Hot Pellets, Hot Chemicals & Fertilizer plants etc. Mainly used for conveying Sintered ore, Hot Cement, Hot Powder, Coke, Hot Chemicals & Fertilizers etc Mainly used to handle red hot materials such as Cement, Clinker, Sintered Ore and Phosphate etc.

Heat Resistant Conveyor Belt Layer to Layer Adhesion Strength
Item The average value of the longitudinal specimen shall be no less than The peak value of the longitudinal specimen
interlayer of cloth 3 2
cover layer and cloth interlayer, Thickness of the cover layer≤1.5mm 2.2 1.6
cover layer and cloth interlayer,Thickness of the cover layer>1.5mm 2.6 2

Heat Resistant Conveyor Belt Abrasive Wear of The Cover Rubber
Item level First Quality Accepts
Abrasive Wear (T1) 0.8 1
Abrasive Wear (T2) 1 1.2
Abrasive Wear (T3) 1 1.2
