Acid and Alkali Resistant Conveyor Belt

Chemical Resistant Conveyor Belt is specially designed, which makes it highly resistant from acids and alkali high concentrations of various chemicals. SKE supply these Acid and alkali chemical resistant conveyor belt.

  • Application
  • Video
  • Features
  • Datasheet
APPLICATION

Chemical Resistant Conveyor belting solutions delivered feature use of superior rubber cover that is made from chemical resistant material and has fine anti-chemical corrosiveness. Also featuring optimum physical properties, these beltings are developed using materials that do not dissolve, expand as well as corrode the belt, thus making these suitable for conveying material with chemical corrosiveness in:

  • Chemical factory,
  • Chemical fertilizer factory,
  • Paper mills,
  • Belting for Mining Industry,
  • Fertilizer industry,
  • Cement Industry,
  • Belting In other areas requiring conveying of acid/alkali-forming materials.

VIDEO
Acid and Alkali Resistant Conveyor Belt
FEATURES

1. These conveyor belts feature superior chemicals and corrosion resistant properties;
2. Having superior elasticity as well as small elongation at rated load;
3. Have superior adhesion, flexibility as well as trough ability;
4. Resistant to most chemicals including chlorinated compounds, acids & bases, coolant oils;
5. Have superior bonding properties with no layer separation;
6. Use of cotton, polyester-cotton, nylon and other material based belt cores that adds to the durability factor as well as resistance from chemicals;

DATASHEET
Physical Property
Item Before Aging After Aging
Tensile Strength(Mpa) 14 12
Elongation At Break(%) 400 340
Abrasion(mm3) 250 ~
Hardness,(o)+10-5 60 65
Ozone Deterioration No Cracks ~

Acid and Alkali Resistance
Class A1 A2 A3
Soak Liquid HCL H2SO4 NaOH
Density 18% 50% 48%
Soak Conditions (oCxh) 50oC x 96h 50oC x 96h 50oC x 96h
Change Rate Before and After Soak,Swelling Rate 0.1 0.1 0.1
Change Rate Before and After Soak,Change Rate of Tensile Strength -0.1 -0.1 -0.1

The Whole Thickness
The Adhesive Strength of Rubber and Cloth Cover > 1.5 mm ≧ 3.2 N/mm
The Adhesive Strength of Rubber and Cloth( Longitudinal) N 3.2 N/mm
Elongation At Break ( Longitudinal) ~ ≧ 10%
